ICEAGE FDQ-204

TTD195.00

Iceage FDQ series

Suction Line Accumulator

1/2" ODF
 PART# FDQ-204


The FDQ series suction line accumulator is designed to protect the compressor from the return of liquid refrigerant.



Features

  >  Temperature of medium: -40 to +120 ºC.

  >  Max. working pressure up to 3.0 Mpa.

  >  Firm powder paint exterior coating for high - resistant from corrosion.

  >  Solder (pure copper) connections.

Choose Quantity
+ Add to Cart
Product Details

Model: FDQ-204

Connection (inch): 1/2 ODF

Dimension (mm)

A:   254

B:   52

D:  102

Flow Capacity (kw)

R22: 7.0

R134A:   4.3

R404A:   4.6

Volume (L): 1.5

 > The flow capacity is based on evaporating temp. +5 ºC.
